DSD TECH: DSD TECH focuses on the development and production of serial devices such as TTL/RS232/RS485., We have provided high-quality products and services to more than 100,000 customers. Each interface provides surge protection.USB protocol standardUSB2.0, backward compatible with USB1.0, USB1.1USB interface standardType-C interfaceRS-232 interface standardStandard DB9 male connector, full-duplex 2:RXD 3:TXD 5: GNDRS-485 interface standard2P 5.08mm terminal block, half-duplexRS-422 interface standard5P 5.08mm terminal block, full-duplexTTL interface standard3P 5.08mm terminal block, default 5V, can be switched to 3.3V through internal jumperPower output2P 5.08mm terminal block, default 100mA@5V, voltage consistent with TTL level voltageIsolation voltage1.5KVStatic protection levelContact 4KV, air 8KVPulse surgeDifferential mode 1KV, common mode 2KVProtection levelIndustrial EMC level 3Baud rate rangeRS-485/RS-422: 300~921600bpsTTL: 300~921600bpsRS-232: 300~460800bpsProduct size122x62x26mmProduct weight120+5gWorking temperature and humidity40~+85C, 5%~95%RH (no condensation)Storage temperature and humidity40~+105C, 5%~95%RH (no condensation) Important Notes This product uses FTDI FT232RL chip by default, because of the chip out of stock, some production batches use FTDI FT232RNL model chip . Usb To 485 Converter DSD TECH SH-U11H Isolated USB To RS485 RS422 Adapter For Industry... Rs485 To Usb Converter The adapter is powered from the USB port and no external power is needed. Two kinds of interfaces: Built-in a 3 PIN Terminal Block interface and a extension cord with alligator clip, the connection is very flexible. It has a 3 PIN Terminal Block on the RS485 port, and a extension cord with alligator clip. The DSD TECH SH-U15 USB to RS485 Cable offers a robust, dual-interface solution for serial communication, featuring a 3-pin terminal block and alligator clip extension. Compatible with major operating systems including Windows, Linux, and Mac OS, it ensures seamless connectivity for professional-grade RS485 networks Packing list: 1 X SH-U15 USB to RS485 Cable 1 X extension cord with alligator clip WARRANTY: DSD TECH offers a 12-month warranty on this USB to RS485 Cable. If you have any questions, please contact us and we will resolve your issue within 24 hours. The SH-U15 is a USB powered USB to RS485 converter , which makes a half-duplex RS485 available to a PC via the USB port. Cable Usb A Rs485 Sh-u15 De Dsd Tech Con Pinzas De Cocodr Jm Kabel USB DSD TECH SH-U11 - bazar
